Spezifikation
Markenname | ALLES IN EINEM |
Modell | AIN7260 |
Garantie | 5 Jahre |
Nennspannung | 76.8V |
Nominale Kapazität | [email protected]/customize |
Energie | 4416Wh |
Interner Widerstand | ≤ 50 mΩ |
Lebensdauer | 4000 Cycles @ 0.2C Charging/Discharging ,Until 80% Capacity |
Selbstentladung | ≤ 3,5% pro Monat bei 25 ° C. |
Max.Ladespannung | 87.6 V |
Lademodus | At 0℃~45℃ temperature, charged to 87.6 V at a constant current of 0.2C, and then,changed continuously with constant voltage of 87.6 V until the current was not more than 0.02C |
Ladestrom | 30A |
Max.Ladestrom | 60A |
Entladestrom | 30A |
Max. discharge Continuous Current | 60A |
Max.Pulsstrom | 120A(<3S) |
Abschaltspannung entladen | 60V |
Ladetemperatur | 0 bis 45 (32 bis 113) bei 60 ± 25% relativer Luftfeuchtigkeit |
Entladungstemperatur | -20 ° C bis 60 ° C (-4 ° C bis 140 ° C) bei 60 ± 25% relativer Luftfeuchtigkeit |
Lagertemperatur | 0 bis 45 (32 bis 113) bei 60 ± 25% relativer Luftfeuchtigkeit |
Wasserstaubbeständigkeit | IP55 |
Zelle & Format | LFP 60AH 24S1P/customize |
Gehäuse | Metal Case |
Abmessung (L * B * H * TH) | anpassen |
Gewicht | 50kg |
Terminal | M6 or Anderson or another bolt screw |
Peak discharge current BMS | 60A |
High temp port. Low temp port. | over charge port. over discharge port. |
Lademethode | CC CV |
Terminal Type | M6 or Anderson or another bolt screw/customize |
Zertifikat | CE, RoHS ,MSDS and UN38.3 certification |
applications | Golf Carts, Electric Forklifts,Slow Speed Car; AGV,Electric Motorcycle; Sightseeing car;RV ,Tricycle, electric vehicles, Electric Wheelchairs, Electric Power Systems, Uninterruptible Power Supplies, Solar Energy Storage Systems,BOATS |
Erinnerung
1.Support customization, according to the specifications required by customers: voltage, capacity, power, working current, size,weight.
2. Factory wholesale price, our factory has a price advantage. Cells of the same level are the cheapest, and you can choose the corresponding cells to make a battery pack according to your requirements.
3.Before placing Order please contact customer service to communicate the required specifications to confirm the price.
Anwendung
Unsere Fabrik
Why to choose us?
* We have our own factory and company, which belong to an absolute integration of industry and trade.
* A large number of batteries are in stock.
* Have very good product resources.
* Good product quality and favorable price.
* The product is 100% original and brand new.
* 100% on time delivery. Fast delivery.(including battery pack <7 days).
* Long warranty 2-5 years.
* provide sample 2-7 days.
* Professional after-sales service.
* We have a complete industrial chain and professional engineers can make battery packs that satisfy you as quickly as
possible.
If you want to know more about the information, please free feel to contact me. Thanks!
Verpackung und Versand
Verpackung
1). Carton Size: customized or based on actual weight and volume, best quality.
2). 5-layers exporting carton or customized outer packaging for paper bags;
Versand
1). By Express (3-30working days),there are express shipping or economic shipping,suitable for small quantity.
2). By Train(25-28days),for EU Country,including customs clearance, all the import tax fees and UPS delivery to the door.
3). By Sea (15-30 days), it suitable for regular mass production.
We cooperate with excellent international freight forwarding companies to provide cheap and efficient logistics services. If you have any shipping issues, please feel free to contact me.
FAQ
F: Wie soll ich bezahlen? Welche Zahlungsarten akzeptieren Sie?
A: T/T, PayPal, Western Union.
F: Ist die Musterbestellung akzeptabel?
A: Ja, für die meisten Batterien sind Musterbestellungen zum Testen der Qualität angemessen und akzeptabel.
F: Ist die Qualität Ihrer Batterie zugelassen?
A: Yes, we guarantee that all cells are 100% original from Brand. And we will have full inspection of each cells and grouping them before assembling into battery packs. And all finished battery packs will be under a full inspection
before shipment.
F: Wie können Sie nachweisen, dass Ihre Zellen zu 100 % original sind?
A: Wir können Ihnen die Original-Packliste und andere zugehörige Dokumente zeigen.
Q: what is your lead time if I placed an order?
A: For all products in stock, our lead time is within 2 working days after payment received. For these that we don't stock for the moment such as customized battery packs, the lead time is around 7-10 days.
F: Was ist Ihre Garantie?
A: These situations not provide return nor refund:
1.After the assembly or assembly process happen any problem, such as the protection board connected to the wrong wire burned lead to battery damage, charger failure, the assembly error or unbalanced assembly, etc.
2. Für verursachte Schäden, wie z. B. Batteriewölbung / geschweißt, Batteriepack ohne Schutz BMS durch Aufladen.
